About S355MC (1.0976) – High-Strength Steel
S355MC, also known by its material number 1.0976, is a hot-rolled, high-strength low-alloy (HSLA) steel designed for excellent formability, weldability, and toughness. It belongs to the EN 10149-2 standard and is primarily used in the automotive, construction, and heavy engineering sectors.
⚙️ Key Features
- ● High yield strength with low weight ratio
- ● Excellent cold forming and bending properties
- ● Outstanding weldability without preheating
- ● Good impact toughness and fatigue resistance
- ● Uniform mechanical properties across thickness range
EN 10149-2 Certified • Fast Delivery Across India
Why Choose Triton for S355MC (1.0976) Steel Plates?
At Triton Alloys Inc. , we supply S355MC in plates, sheets, and coils, customized to your dimensional and mechanical requirements. Each plate undergoes rigorous quality checks to ensure compliance with EN 10149-2 specifications, ensuring consistent performance across batches.
- ● Certified S355MC (1.0976) Plates with guaranteed mechanical and chemical properties.
- ● Largest stock range in India with ready availability in various sizes and thicknesses.
- ● Competitive, transparent pricing tailored for fabricators, EPC contractors, and plant builders.
- ● Global export expertise to 80+ countries with reliable shipping and documentation support.
- ● Cut-to-size, profile cutting, and edge preparation services for immediate project use.
- ● ISO 9001:2015 certified supplier with strict quality checks and third-party inspection options.
Need S355MC Plates for Fabrication or OEM Projects?
Get ready stock availability, thickness options, EN 10149-2 certification details, and latest S355MC plate prices directly from our steel experts.
Used by fabricators, automotive OEMs, trailer manufacturers & EPC contractors across India.
Specifications of S355MC Steel Plates
| Grade | S355MC |
|---|---|
| Number: | 1.0976 |
| Standard | EN 10149-2 |
| Thickness range | 1.5 – 20mm (grade specific) |
| Width range | 750 – 2070mm (grade specific) |
Mechanical Properties of S355MC (1.0976) Plates
| Standard | Grade (Material) |
Rm - Tensile strength (MPa) | ReH - Minimum yield strength (MPa) | Elongation at fracture A, ≥ | |
| EN 10149-2 | S355MC (1.0976) |
430-550 | 355 | 19 (t≤ 3), Lo = 80 mm | 23 (t≥ 3), Lo = 5.65 √So |
Equivalent Grades of S355MC (1.0976)
| EU EN |
USA | Germany DIN,WNr<30mm |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
Spain UNE |
Sweden SS |
Inter ISO |
| S355MC | Gr.50 | QStE360TM | SPFH540 |
E355D E390D |
46F35 46F40 |
FeE355TM | AE390HC | 2642 | FeE355 |
Chemical Composition of S355MC Steel Plates
Typical maximum values (% by weight) as per EN 10149-2:
| C | Si | Mn | P | S | Al | Nb | V | Ti |
|---|---|---|---|---|---|---|---|---|
| 0.12 max | 0.50 max | 1.50 max | 0.025 max | 0.020 max | 0.015 min | 0.09 max | 0.20 max | 0.15 max |
Note: The sum of Nb + V + Ti shall not exceed 0.22 %.
Looking for S355MC Plate Supplier in India?
Triton Alloys Inc. supplies EN 10149-2 S355MC plates with test certificates, custom cutting, and fast delivery across Mumbai, Pune, Ahmedabad, Chennai, Hyderabad, Bangalore and PAN India.
Popular Types of S355MC Steel Plate
EN 10149-2 S355MC Steel Plate
EN 1.0976 Sheet
S355MC Plate
S355MC Material
EN 10149-2 S355MC Plates
EN 10149-2 Grade S355MC Plates
How to Select the Right S355MC Plate for Your Project
Choosing the correct S355MC steel plate depends on application type, forming requirements, welding conditions, and load-bearing expectations. S355MC is widely preferred for cold forming and structural fabrication because of its excellent strength-to-weight ratio and superior formability.
- S355MC for Automotive Chassis: Used in trailer frames, truck bodies, and transport equipment due to lightweight high-strength properties.
- S355MC for Heavy Fabrication: Ideal for crane parts, lifting equipment, industrial platforms, and structural fabrication.
- S355MC for Cold Forming: Preferred for bending, folding, and roll-forming applications requiring crack resistance.
- S355MC for OEM Manufacturing: Used by engineering and machinery manufacturers requiring consistent EN 10149-2 mechanical properties.
At Triton Alloys Inc., we help clients choose the correct thickness, width, processing option, and certification requirement based on their project needs.
Applications of S355MC Steel Plates in India
The S355MC grade is ideal for high-yield structural applications, especially where cold forming or fabrication is involved. Key uses include:
- ◇ Structural components in buildings, bridges and frameworks.
- ◇ Cold-formed parts such as automotive components, chassis, bodywork.
- ◇ Pressure vessels, tanks, containers and heavy fabrication where high strength and good formability are required.
- ◇Any industrial project demanding the combination of 355 MPa yield, good weldability and dimensional stability.
Heat treatment conditions
| +A Soft annealed | +P Precipitation hardened |
| +AC Annealed to achieve spheroidization of the carbides | +PE Peeled |
| +AR As rolled | +QA Air quenched and tempered |
| +AT Solution annealed | +QL Liquid quenched and tempered |
| +C Cold drawn / hard | +QT Quenched and tempered |
| +CR Cold rolled | +S Treated to improve shearability |
| +FP Treated to ferrite-pearlite structure and hardness range | +SH As rolled and turned |
| +I Isothermal annealing | +SR Cold drawn and stress relieved |
| +LC Cold drawn / soft | +T Tempered |
| +M Thermo mechanical rolling | +TH Treated to hardness range |
| +N Normalized | +WW Warm worked |
| +NT Normalized and tempered | +U Untreated |
S355MC Steel Plates – Frequently Asked Questions (FAQs)
Find answers related to S355MC steel plate price, thickness, welding, applications, EN 10149-2 specifications, equivalent grades, and structural fabrication uses in India.
S355MC steel plates are widely used in automotive chassis manufacturing, truck body fabrication, trailers, structural fabrication, construction equipment, railway wagons, agricultural machinery, and cold-formed engineering components due to their high strength and excellent formability.
In S355MC, “M” indicates thermomechanically rolled steel and “C” denotes suitability for cold forming applications. The grade is designed for high-strength structural applications requiring good bending and welding properties.
Yes. S355MC plates offer excellent weldability and are commonly used for laser cutting, bending, forming, robotic welding, and heavy structural fabrication. Their fine-grain structure reduces cracking risk during processing.
S355MC plates have a minimum yield strength of 355 MPa as per EN 10149-2 standards, making them suitable for lightweight yet high-load structural applications.
Equivalent grades of S355MC include QStE360TM, FeE355TM, E355D, and other thermomechanically rolled structural steels used globally for fabrication and engineering applications.
S355MC steel plates are commonly available in thicknesses ranging from 1.5 mm to 20 mm, depending on project requirements, processing needs, and stock availability.
S355MC is a thermomechanically rolled steel mainly used for cold-forming applications with superior formability, while S355JR is a general structural steel grade primarily used in construction and load-bearing structures.
Triton Alloys Inc. is a trusted supplier and stockist of S355MC steel plates in Mumbai, India, offering ready stock, custom sizes, fast delivery, EN 10149-2 certified material, and bulk supply support across India.
